SES POWER DCB SERIES

1) "SS" means Standard Series

LiFePO4 batteries are an ideal replacement for a traditional lead acid battery, offering a drop-in solution for lead acid battery replacement. SES Power batteries can be used individually or connected in series or parallel to create a larger system.The series LiFePO4 battery is fit for E-mobility, Energy Storage System, Defense & Security, telecom outdoor applications,renewable energy systems, and other harsh environment applications.

If you are interested in a model, please click on the corresponding name in MODEL NO.

Model No	Nominal Voltage (V)	Nominal Capacity (Ah)	Max. Charge Current (A)	Max. Cont. Discharge Current (A)	Terminal Type Layout	Discharge Temp. Range (℃)	Dimensions (LWH mm)	Weight (kg)	Max. in Series
DCB-1207-Y09-SS	12.8	7	7	15	F2 &Layout D	-20-+60	1516599	0.9	4
DCB-1212-Y19- SS	12.8	12	12	30	M6 &Layout D	-20-+60	15198101	1.7	4
DCB-1230-Y26- SS	12.8	30	30	30	M6 &Layout B	-20-+60	18176167	3.7	4
DCB-1240-Y29- SS	12.8	40	40	40	T11 &Layout C	-20-+60	174165130	4.7	4
DCB-1245-Y36- SS	12.8	45	45	45	T11 &Layout A	-20-+60	195133178	5.3	4
DCB-1250-Y38- SS	12.8	50	50	50	T11 &Layout B	-20-+60	198166170	6.0	4
DCB-1260-Y38- SS	12.8	60	60	60	T11 &Layout B	-20-+60	198166170	6.8	4
DCB-1260-Y39- SS	12.8	60	60	60	T11 &Layout A	-20-+60	230138213	6.8	4
DCB-1280-Y43- SS	12.8	80	80	80	T11 &Layout A	-20-+60	260168214	9.0	4
DCB-12100-G31-SS	12.8	100	100	100	T11 &Layout A	-20-+60	329172223	11.0	4
DCB-12120-Y44-SS	12.8	120	120	120	T11 &Layout A	-20-+60	307168214	13.0	4
DCB-12150-Y47-SS	12.8	150	150	150	T11 &Layout A	-20-+60	406173238	16.0	4
DCB-12200-G8D-SS	12.8	200	200	200	T11 &Layout C	-20-+60	520242229	21.0	4
DCB-12200-Y48-SS	12.8	200	200	200	T11 &Layout A	-20-+60	483172242	21.0	4
DCB-12250-G8D-SS	12.8	250	200	200	T11 &Layout C	-20-+60	520242229	26.0	4
DCB-12300-G8D-SS	12.8	300	200	200	T11 &Layout C	-20-+60	520242229	32.0	4
DCB-12400-G8D-SS	12.8	400	200	200	T11 &Layout C	-20-+60	520242229	42.0	4
DCB-2450-G31-SS	25.6	50	50	50	T11 &Layout A	-20-+60	329172223	11.0	2
DCB-2450-Y44-SS	25.6	50	50	50	T11 &Layout A	-20-+60	307168214	11.0	2
DCB-2480-Y47-SS	25.6	80	80	80	T11 &Layout A	-20-+60	406173238	17.0	2
DCB-24100-G8D-SS	25.6	100	100	100	T11 &Layout C	-20-+60	520242229	21.0	2
DCB-24100-Y48-SS	25.6	100	100	100	T11 &Layout A	-20-+60	483172242	21.0	2
DCB-24150-G8D-SS	25.6	150	150	150	T11 &Layout C	-20-+60	520242229	32.0	2
DCB-24200-G8D-SS	25.6	200	200	200	T11 &Layout C	-20-+60	520242229	42.0	2
DCB-4850-Y48-SS	51.2	50	50	50	T11 &Layout A	-20-+60	483172242	21.0	1
DCB-48100-G8D-SS	51.2	100	100	100	T11 &Layout C	-20-+60	520242229	42.0	1

2)"SC" means Standard Plus communication

SES Power SC series LiFePO4 battery has a built-in bluetooth module(Optional RS485 or Can) that lets you communicate with the battery using our free APP & software for Andriod mobile & computer. You can check the battery capacity or State of Charge (SoC), voltage, temperature, charge or discharge current simply.The SC series is an ideal choice for use in RVs, off-grid solar,marine, renewable energy system, etc.

If you are interested in a model, please click on the corresponding name in MODEL NO.

Model No	Nominal Voltage (V)	Nominal Capacity (Ah)	Max. Charge Current (A)	Max. Cont. Discharge Current (A)	Terminal Type Layout	Discharge Temp. Range (℃)	Dimensions (LWH mm)	Weight (kg)	Max. in Series
DCB-1230-Y26-SC	12.8	30	30	30	M6 &Layout B	-20-+60	18176167	3.7	4
DCB-1240-Y29-SC	12.8	40	40	40	T11 &Layout C	-20-+60	174165130	4.7	4
DCB-1245-Y36-SC	12.8	45	45	45	T11 &Layout A	-20-+60	195133178	5.3	4
DCB-1250-Y38-SC	12.8	50	50	50	T11 &Layout B	-20-+60	198166170	6.0	4
DCB-1260-Y38-SC	12.8	60	60	60	T11 &Layout B	-20-+60	198166170	6.8	4
DCB-1260-Y39-SC	12.8	60	60	60	T11 &Layout A	-20-+60	230138213	6.8	4
DCB-1280-Y43-SC	12.8	80	80	80	T11 &Layout A	-20-+60	260168214	9.0	4
DCB-12100-G31-SC	12.8	100	100	100	T11 &Layout A	-20-+60	329172223	11.0	4
DCB-12120-Y44-SC	12.8	120	120	120	T11 &Layout A	-20-+60	329172223	13.0	4
DCB-12150-Y47-SC	12.8	150	150	150	T11 &Layout A	-20-+60	406173238	16.0	4
DCB-12200-G8D-SC	12.8	200	200	200	T11 &Layout C	-20-+60	520242229	21.0	4
DCB-12200-Y48-SC	12.8	200	200	200	T11 &Layout A	-20-+60	483172242	21.0	4
DCB-12250-G8D-SC	12.8	250	200	200	T11 &Layout C	-20-+60	520242229	26.0	4
DCB-12300-G8D-SC	12.8	300	200	200	T11 &Layout C	-20-+60	520242229	32.0	4
DCB-12400-G8D-SC	12.8	400	200	200	T11 &Layout C	-20-+60	520242229	42.0	4
DCB-2450-G31-SC	25.6	50	50	50	T11 &Layout A	-20-+60	329172223	11.0	2
DCB-2450-Y44-SC	25.6	50	50	50	T11 &Layout A	-20-+60	307168214	11.0	2
DCB-2480-Y47-SC	25.6	80	80	80	T11 &Layout A	-20-+60	406173238	17.0	2
DCB-24100-G8D-SC	25.6	100	100	100	T11 &Layout C	-20-+60	520242229	21.0	2
DCB-24100-Y48-SC	25.6	100	100	100	T11 &Layout A	-20-+60	483172242	21.0	2
DCB-24150-G8D-SC	25.6	150	150	150	T11 &Layout C	-20-+60	520242229	32.0	2
DCB-24200-G8D-SC	25.6	200	200	200	T11 &Layout C	-20-+60	520242229	42.0	2
DCB-4850-Y48-SC	51.2	50	50	50	T11 &Layout A	-20-+60	483172242	21.0	1
DCB-48100-G8D-SC	51.2	100	100	100	T11 &Layout C	-20-+60	520242229	42.0	1
