Are you still using heavy, environmentally unfriendly lead-acid batteries as a starter?
Are you still bothered by the short life, temperature limit, and power limit of normal starting batteries?
Are you still bothered by the large space occupied and difficult assembly of normal starting batteries?
Use SES Power's lithium ion starting battery, it will change your perspective.
We use high-quality lithium ion cells to make the starter battery, and of course, it has excellent performance BMS as a protector. Lithium iron phosphate cell are the main components of our starting batteries.
We can provide CCA@450A, CCA@900A, CCA@1200A, CCA@1800A performance of the start-up battery.
We can provide High-Rate batteries with continuous maximum discharge current up to 1500A.
You can easily replace lead acid starter batteries with SES Power's starting batteries, which are widely used in automotive startup, UPS, data centers, Marine Power, motors, emergency equipment, and more.
Low temperature is also a key consideration, and our starting battery can effectively output at -40 degrees Celsius. Of course, smart is also what we pursue. Our battery can be equipped with software functions, so you can check the real-time status of the battery at any time on your computer or mobile phone.
5) "HP" means High Power Series
SES Power HP series LiFePO4 batteries has very strong output power and replacement for star type lead acid battery, offering a drop-in solution for lead acid battery replacement. SES Power batteries can be used individually or connected in series or parallel to create a larger system.The series LiFePO4 battery is fit for E-mobility,Motor star, Energy Storage System, Defense & Security,high power UPS,renewable energy systems, and other harsh environment applications.
Model No | Nominal Voltage (V) | Nominal Capacity (Ah) | Max. Charge Current (A) | Max. Cont. Discharge Current (A) | Terminal Type & Layout | Discharge Temp. Range (℃) | Dimensions (L*W*H mm) | Weight (kg) | Max. in Series |
DCB-5C1207-Y09-HP | 12.8 | 7 | 7 | 35 | F2 & Layout D | -20-+60 | 151*65*99 | 0.9 | 4 |
DCB-5C1212-Y19- HP | 12.8 | 12 | 12 | 60 | M6&Layout D | -20-+60 | 151*98*101 | 1.7 | 4 |
DCB-5C1230-Y26- HP | 12.8 | 30 | 30 | 150 | M6 &Layout B | -20-+60 | 181*76*167 | 3.7 | 4 |
DCB-5C1240-Y29- HP | 12.8 | 40 | 40 | 200 | T11 &Layout C | -20-+60 | 174*165*130 | 4.7 | 4 |
DCB-5C1250-Y38- HP | 12.8 | 50 | 50 | 350 | T11 &Layout B | -20-+60 | 198*166*170 | 6.0 | 4 |
DCB-5C1260-Y38- HP | 12.8 | 60 | 60 | 300 | T11 &Layout B | -20-+60 | 198*166*170 | 6.8 | 4 |
DCB-5C1260-Y39- HP | 12.8 | 60 | 60 | 300 | T11 &Layout A | -20-+60 | 230*138*213 | 6.8 | 4 |
DCB-3C12100-G31-HP | 12.8 | 100 | 100 | 300 | T11 &Layout A | -20-+60 | 329*172*223 | 11.0 | 4 |
DCB-5C2450-G31-HP | 25.6 | 50 | 50 | 250 | T11 &Layout A | -20-+60 | 329*172*223 | 11.0 | 2 |
DCB-3C24100-G8D-HP | 25.6 | 100 | 100 | 300 | T11 &Layout C | -20-+60 | 520*242*229 | 21.0 | 2 |
DCB-3C24150-G8D-HP | 25.6 | 150 | 150 | 450 | T11 &Layout C | -20-+60 | 520*242*229 | 32.0 | 2 |
DCB-5C4850-Y48-HP | 51.2 | 50 | 50 | 250 | T11 &Layout A | -20-+60 | 483*172*242 | 21.0 | 1 |
DCB-3C48100-G8D-HP | 51.2 | 100 | 100 | 300 | T11 &Layout C | -20-+60 | 520*242*229 | 42.0 | 1 |
6)"HC" means plus Communication
SES Power HC series LiFePO4 batteries has not only strong output power but also built-in bluetooth module(Optional RS485 or Can) that lets you communicate with the battery using our free APP & software for Andriod mobile & computer. You can check the battery capacity or State of Charge (SoC), voltage, temperature, charge or discharge current simply.The HC series is an ideal choice for use in RVs, Motor star,UPS,off-grid solar,marine, renewable energy system, etc.
Model No | Nominal Voltage (V) | Nominal Capacity (Ah) | Max. Charge Current (A) | Max. Cont. Discharge Current (A) | Terminal Type & Layout | Discharge Temp. Range (℃) | Dimensions (L*W*H mm) | Weight (kg) | Max. in Series |
DCB-5C1230-Y26- HC | 12.8 | 30 | 30 | 150 | M6 &Layout B | -20-+60 | 181*76*167 | 3.7 | 4 |
DCB-5C1240-Y29- HC | 12.8 | 40 | 40 | 200 | T11 &Layout C | -20-+60 | 174*165*130 | 4.7 | 4 |
DCB-5C1250-Y38- HC | 12.8 | 50 | 50 | 350 | T11 &Layout B | -20-+60 | 198*166*170 | 6.0 | 4 |
DCB-5C1260-Y38- HC | 12.8 | 60 | 60 | 300 | T11 &Layout B | -20-+60 | 198*166*170 | 6.8 | 4 |
DCB-5C1260-Y39- HC | 12.8 | 60 | 60 | 300 | T11 &Layout A | -20-+60 | 230*138*213 | 6.8 | 4 |
DCB-3C12100-G31-HC | 12.8 | 100 | 100 | 300 | T11 &Layout A | -20-+60 | 329*172*223 | 11.0 | 4 |
DCB-5C2450-G31-HC | 25.6 | 50 | 50 | 250 | T11 &Layout A | -20-+60 | 329*172*223 | 11.0 | 2 |
DCB-3C24100-G8D-HC | 25.6 | 100 | 100 | 300 | T11 &Layout C | -20-+60 | 520*242*229 | 21.0 | 2 |
DCB-3C24150-G8D-HC | 25.6 | 150 | 150 | 450 | T11 &Layout C | -20-+60 | 520*242*229 | 32.0 | 2 |
DCB-5C4850-Y48-HC | 51.2 | 50 | 50 | 250 | T11 &Layout A | -20-+60 | 483*172*242 | 21.0 | 1 |
DCB-3C48100-G8D-HC | 51.2 | 100 | 100 | 300 | T11 &Layout C | -20-+60 | 520*242*229 | 42.0 | 1 |
